    XYC-03 Magnetic Switch

    Ask Lasest Price
    Supply Ability : 10000 Piece/Pieces per Month
    Payment Terms : T/T,L/C,PAYPAL
    • Product Details
    • Company Profile

    XYC-03 Magnetic Switch

    Product Detail

    Product Tags

    Specifications

    ModelXYC-03RXYC-03NXYC-03P
    CharacteristicsConnect Diagram
    Wiring Method2-Wire Type3-Wire Type
    Switching LogicSPST Nomally OpenSolid State Output,Normally Open
    Sensor TypeReed SwitchNPN Current SinkingPNP Current Sourcing
    Operating Voltage5~240V DC/AC5~30V DC
    Max.Switching Current100mA max.200mA max.
    Contact Rating10W max.6W max.
    Current Consumption-8mA @ 24V DC max.
    Voltage Drop3.0V max.1V @ 200mA max.
    Leakage Current-0.01mA max.
    IndicatorLED/Red LEDRed LEDGreen LED
    CableΦ2.8, 2C, PVCΦ2.8, 2C, PVC
    Max.Operating Frequency200HZ1000HZ
    Temperature Range-10~70℃
    Shock30G50G
    Vibration9G
    Enclosure ClassificationIEC 529 IP67(NEMA6)
    Protection Circuit-With Protection

    Overall Dimension

    Mounting Clamp


    M8 Pin out
