SDA compact cylinder

Ask Lasest Price
Supply Ability :	10000 Piece/Pieces per Month
Payment Terms :	T/T,L/C,PAYPAL

Add to Cart

Product Details
Company Profile

SDA compact cylinder

Product Detail

Product Tags

Ordering Code 未标题-1.jpg

Specification

Bore(mm)		12	16	20	25	32	40	50	63	8	100
Motion Pattern		Double Action
		Single Action Extrusion type/ Single Action Drawing-in Type						_
Working Medium		Air
Operating Pressure Range	Double Action	0.1~0.9MPa
	Single Action	0.2~0.9MPa						_
Ensured Pressure Resistance		1.35MPa
Operating Temperature Range		-5~70
Operating Speed Range	Double Action	30~50mm/s						30~350mm/s		30~250mm/s
	Single Action	100~50mm/s						-
Buffer Type		Fixed Type Buffer
Port Size		M5×0.8				G1/8″		G1/4″		G3/8″

Stroke

Bore(mm)

100

Double Action

Without Magnet
